High Anti-glare type-ACRO Industrial Co., Ltd

Product Features:

good-looking, anti-dizziness, bright, low-glare types
Z-753-10R ・・・ anti-dizziness coating liquid
Z-753-11R ・・・ add more UV coating liquid
Z-753-10C ・・・ ClearUV coating liquid

proimages/products/Agents-Electronic-Materials-AICA/06.png

Property:

Ratio blending and Optics:

		Z-753-10RL	evaluation methodology
characteristic	Solid content	50%
	Solvent composition	Toluene / IBA
	Viscosity	60～90mPa・s
Properties	Total light transmittance	92.0%	JIS K 7361
	Haze	0.5～35%	JIS K 7136
	Pencil hardness	3H	JIS K 5600
	Scratch-resistance	○	SW(#0000), 2kg×10cycles

※Dry film is formed on the 125umPET 5um

Haze (%)	Ratio blending
Haze (%)	Z-753-10R	Z-753-11R	Z-753-10C
0.3	0	0	100
2.0	70	0	30
4.0	90	0	10
6.0	100	0	0
9.0	20	80	0
11	0	100	0

※ want to improve more than 11%,
please inquire separately.
